ICR-2041

Life Cycle: production

Regions: NAM

Entry-Level 4G router
LTE Cat.4 with 3G fallback
for NAM region

Technical description

The industrial cellular router ICR-2041 is designed for wireless communication to enable the connection of IP devices to a cellular network. Industrial M2M and IoT applications include kiosks, industrial PCs, HMIs, traffic controllers, meters, UPS systems, and much more. The peak downlink data rate for LTE Cat.4 is approximately 150 Mbps. Also in the uplink, LTE Cat.4 provides a peak data rate of 50 Mbps.
The router is equipped with one Ethernet port (LAN) and with digital I/O connectivity (1x DI, 1x DO). The router supports VPN tunnel creation using various protocols to ensure safe communications. The router provides diagnostic functions which include automatic monitoring of the wireless and wired connections, automatic restart in case of connection losses, and a hardware watchdog that monitors the router status.
The router is based on the ICR-OS operation system. Open Linux platform enables wide possibilities of programming customer SW applications in Python and C/C++. The router supports uploading of RouterApps that would extend standard firmware functionalities. The existing app library ready for free download by customers contains already developed software apps to enhance
specific router functionality including industrial protocol conversions, support of IoT platforms such as MS Azure, Cumulocity, ThingWorx, and a lot more.

Compatible accessories

• Antennas
• Cables
• Power sources
• Other
